4 Channels Network NVR-9004 Redline Recorder

4 Channels Network NVR-9008 Redline Recorder

 Support Ultra 265/H.265/H.264 video formats

4-channel input

Plug & Play with 8 independent PoE network interfaces

Third-party IP cameras supported with ONVIF conformance: Profile S, Profile G, Profile T

Support 1-ch HDMI, 1-ch VGA

HDMI and VGA simultaneous output

Up to 8MP resolution recording

1 SATA HDD up to 6TB

Support cloud upgrade

4-ch

Incoming Bandwidth 50Mbps

Outgoing Bandwidth 40Mbps

Remote Users 128

Protocols P2P, UPnP, NTP, DHCP, PPPoE

HDMI/VGA Output HDMI: 3840x2160/30Hz , 1920x1080/60Hz,

1920x1080/50Hz, 1600x1200/60Hz,

1280x1024/60Hz, 1280x720/60Hz,

1024x768/60Hz

VGA: 1920x1080/60Hz, 1920x1080/50Hz,

1600x1200/60Hz, 1280x1024/60Hz

1280x720/60 1024x768/60Hz

Recording Resolution 8MP/5MP/4MP/3MP/1080P

/960P/720P/960H/D1/2CIF/CIF

Synchronous Playback 4-ch

Corridor Mode Screen 3/4/5/7/9

Decoding format Ultra 265/H.265/H.264

Liveview/Playback 8MP/5MP/4MP/3MP

/1080P/960P/720P/960H/D1/2CIF/CIF

capability 1 x 8MP@30 , 1 x 5MP@30 ,

2 x 4MP@30 , 4 x 3MP@20

4 x 1080p@30 , 8 x 720p@30

SATA 1 SATA interface

capacity up to 6TB for each disk

Network Interface 1 RJ45 10M/100M,

self-adaptive Ethernet Interface

USB Interface Rear panel: 2 x USB2.0

interface 8 independent 100 Mbps PoE network interfaces

MaxPower Max 30W for single port

Max 108W in total (13.5W for each)

Supported Standard IEEE 802.3at, IEEE 802.3af

Power Supply

48V DC

Power Consumption: ≤5 W (without HDD)

Working Environment -10°C ~ + 55°C (+14°F ~ +131°F),

Humidity ≤ 90% RH (non-condensing)

Weight (without HDD) ≤1.2kg (2.65lb)
